Direct Answer: Via surface finishing falls into three processes — tenting, plugging, and fill-and-cap — corresponding to IPC-4761 Type I, Type III/IV and Type VII. Ordinary signal/power vias can be tentled by default (keep the via diameter within 0.5mm); test probing, high-current paths and thermal relief arrays must be opened to expose copper; and vias landing inside pads — especially under BGA packages — require resin filling, planarization and copper capping, where both tenting and opening are inadequate. Choose wrong, and you risk wave-solder wicking, probe tips dropping into holes, and BGA solder-joint defects.

Many layout engineers habitually tick "tent" or "open" when handling vias, but this is not a styling preference — it is a process decision that directly affects manufacturability, testability and reliability. Here is the selection logic, broken down.

1. Get the Concepts Right: Tenting, Plugging and Fill-and-Cap Are Not the Same Thing

Via Tenting：Solder mask covers the via opening，Hollow inside ， Type I

Via Plugging： Ink/resin actually fills the hole ， Solidly plugged ， Type III / IV

Fill & Cap： Resin filled → planarized → copper-capped ， Coplanar with the pad ， Type VII

- Via Tenting (Type I): Solder mask covers only the opening, keeping solder away from the via and providing basic insulation; the hole remains hollow.

- Via Plugging (Type III/IV): Ink or resin is pushed into the hole to stop solder from climbing up the barrel — this is plugging, not tenting.

- Fill & Cap (Type VII): The via is filled with resin, ground flat, and copper-capped so the surface is coplanar with the pad — the specified solution for BGA via-in-pad.

The first question in selection is not "open or tent?" but: Does this via need to be solidly filled? Does it need to be soldered to? Does a probe need to contact it?

2. For Most Vias, Tenting by Default Is Correct

Ordinary signal vias and ordinary power vias — not tested, not carrying heat, not landing in pads — tenting is the standard and lowest-cost choice. Two limits to keep in mind:

1. Diameter control: Tented vias are best kept ≤0.4mm, and should not exceed 0.5mm. Beyond that, ink can no longer reliably cover the annular ring, and fabricators generally will not accept responsibility for such tenting defects.

2. "Yellowish" openings are not defects: As liquid solder mask cures, it flows slightly into the hole, thinning the ink at the annular ring and letting the copper show through. This yellowish appearance is inherent to the tenting process, not a sign of poor coverage.

Important: tenting seals the mouth, not the hole. In wave soldering and selective soldering, the hole remains hollow and solder can still wick through — tenting alone is insufficient for these scenarios.

3. Three Cases Where Vias Must Be Opened

① ICT/FCT probe testing

The solder mask is insulating; a tented via prevents the probe from contacting copper, making the test useless. Test vias must be opened on the probe side to expose copper. A common pitfall: **do not open without plugging** — with a bare opened hole, the probe tip can sink into the barrel, causing unstable contact and fixture damage. The robust approach is to plug or fill first, then open.

② High-current paths where a single via cannot carry the current

Take a 0.3mm via with 25µm barrel copper: with good outer-layer cooling and a 10℃ temperature rise, one via handles about 1A reliably; approaching 2A depends on thermal conditions. Routing 3A or 5A through a single via is poor practice. Parallel multiple vias and open them so reflow solder wraps the annular ring, effectively enlarging the conductive and thermal cross-section. Note this benefit depends on solder actually filling in — opening a via itself does not conduct current.

③ Via arrays under thermal pads

Solder mask adds thermal resistance; opening the vias lets copper contact air or thermal interface material directly, forming part of the heat dissipation path.

Opening also has costs: bare copper oxidizes, and adjacent opened vias are prone to solder bridging during HASL. The industry baseline is **via pad edge to adjacent pad edge ≥0.2mm**; if layout cannot fit this, switch to ENIG (immersion gold) to reduce bridging risk.

4. Via-in-Pad: Neither Tenting nor Opening Is Enough

When a via lands inside a pad — especially under a BGA package — the problem escalates. During reflow, unfilled via-in-pad allows molten solder to be drawn up the barrel (solder wicking), causing voids, insufficient solder, and ultimately BGA cold/weak joints.

Therefore via-in-pad needs neither tenting nor bare opening — it requires **Type VII: resin filling + planarization + copper capping**. Ink plugging is unsuitable here: ink cracks under thermal cycling, traps voids, and cannot achieve the flatness BGA pads require. Holes inside pads must be filled with resin or copper paste.

Another easily overlooked thermal-design point: corner BGA filled vias that are not connected to a large inner-layer copper plane may suffer cold tear / solder shrinkage cracking during rapid cooling after reflow — the fill solution must be evaluated together with the inner-layer copper design.

5. Design-to-Fab Checklist

- After choosing tenting in the design file, keep the Gerber solder mask layer consistent — file intent must match process intent.

- Do not just draw via-in-pad; explicitly note in the fabrication note: **"IPC-4761 Type VII, resin filled, copper capped."**

- Prefer "fill/plug then open" for test vias, and verify probe contact area matches the via diameter.

- Annotate current-carrying and thermal intent in the stackup sheet for DFM review.

6. Juehui Weiye Circuit: Via Selection Is Where Design Intent Meets Process Capability

Via handling is one of the most frequently checked items in our DFM review, distilled into four practices:

- Upfront DFM check: On receiving Gerber files, we verify that via types match the solder mask layer and fabrication notes. High-risk combinations such as "via-in-pad tentled" are flagged and fed back immediately — not discovered after assembly failures.

- Full process stack: We support IPC-4761 Type I tenting, Type III/IV plugging (resin/ink), and Type VII resin filling + planarization + copper capping, with via-in-pad flatness meeting BGA soldering requirements.

- High-current specials: We perform current-carrying and thermal-rise evaluation for power vias, and recommend process solutions around opening, paralleling and thermal design.

- Full traceability: Filling/capping inspection data is provided for critical batches, delivered together with TDR and impedance reports.
