Multi-channel Industrial Test System PCBA Mainboard

This is a multi-channel industrial test system PCBA mainboard, Board No. 37I-AD-Test System 4CH 24V V8.0. It is a rectangular industrial control board manufactured by integrated PCB fabrication, SMT assembly and DIP through-hole insertion. Powered by STM32H743 high-performance MCU, it integrates multi-channel signal acquisition circuit, high-power drive circuit, Gigabit Ethernet communication, CPCI European connectors and green plug terminals. It supports multi-channel AD acquisition, signal output, high-power load drive and Ethernet data upload. Equipped with independent heat dissipation modules and separated layout for strong/weak current, the board is built with complete power protection circuits. Specially designed for industrial automatic test equipment, it features excellent EMC performance and stable long-term continuous operation.

Juehui Weiye Circuit provides full-set manufacturing capabilities for industrial PCBA. We support one-stop custom services including PCB prototyping, SMT assembly, DIP insertion and functional burn-in test for industrial control boards in small & medium batches.

Basic Parameters

- PCB Dimension: 218*144mm

- Total Solder Points: 4200 points

- Component Types: 216 types

- Minimum Package: QFN / 0402

- Minimum Pin Pitch: 0.35mm

- Soldering Method: 10-zone lead-free reflow soldering + wave soldering + post soldering reinforcement for high-power components

- Board No.: 37I-AD-Test System 4CH 24V V8.0

- Base Material: High TG FR-4

- Board Thickness: 1.6mm

- Surface Finish: Hard Gold Plating

- Flame Retardant Grade: UL94 V-0

- Power Input: DC24V

- Main Controller: STM32H743 High-performance Industrial MCU

- Storage: On-board Flash IC

- Interfaces: Gigabit Ethernet, CPCI European Connector, Multi-channel Green Terminal Blocks

- Core Function: 4-channel AD signal acquisition, analog signal output, high-power channel driving

- Protection Circuit: Fuse, TVS, filter circuit, overvoltage / overcurrent / short-circuit protection

PCBA Manufacturing Process

Process Flow

PCB Fabrication → SMT Solder Paste Printing (SPI Inspection) → High-speed SMT Mounting → 10-zone Reflow Soldering → AOI Optical Inspection → Automatic & Manual DIP Insertion → Wave Soldering → Post Soldering for High-power Components & Heat Sink Assembly → Board Cleaning → Trimming & Rework → Hi-pot Insulation Test → Power-on Functional Test → Burn-in Aging Test → Full-channel Function Verification → Full Visual Inspection → ESD Finished Packaging

1. SMT Assembly Process

- Automatic solder paste printing with SPI online solder paste inspection to control solder volume for tiny components.

- High-speed mounter for STM32 main chip, flash memory, QFN, 0402 SMD resistors & capacitors, MOSFET and signal conditioning ICs.

- 10-zone segmented temperature control reflow oven to reduce thermal deformation of large-size PCB.

- AOI automatic optical inspection to detect cold solder, insufficient solder, component offset, tombstoning and wrong parts.

2. DIP Insertion Process

- Automatic + manual insertion for electrolytic capacitors, power resistors, connectors, terminals and high-power diodes.

- Wave soldering for through-hole components.

3. Post-assembly Process

- Post soldering reinforcement and heat sink locking for high-power devices;

- Cleaning to remove flux residue;

- Electrical performance test: insulation withstand voltage, power circuit and signal channel test;

- Long-time burn-in test to screen early failure components;

- Full inspection for signal acquisition and output functions;

- Recheck of appearance, connectors and terminals, packed with ESD protection.

> Assembly Features: Hybrid assembly combining high-density SMT signal chips and high-power DIP power components. Isolated layout for strong and weak current, heat dissipation design for high-power loops. Meets safety and EMC requirements of industrial equipment for long-time non-stop operation.

Product Advantages

1. High-performance Multi-channel Signal Acquisition

Adopts STM32H7 industrial MCU, with 4 independent AD channels for high-precision sampling and analog output. Real-time multi-sensor data collection and high-speed data upload via Gigabit Ethernet for automatic production line testing.

2. High-power Drive & Optimized Heat Dissipation

Built-in multi-channel high-power drive circuits with independent heat sink modules. High-power components are locked and reinforced, stable under continuous load with 24V industrial power supply, suitable for long-time continuous test.

3. Rich Industrial Interfaces & Strong Compatibility

Equipped with CPCI backplane connectors, pluggable green terminal blocks and Gigabit Ethernet port. Easy to integrate into test cabinets and connect sensors, actuators and host computer.

4. Multi-level Electrical Protection & Anti-interference

Integrated TVS surge suppressor, overcurrent fuse and common-mode filter. Isolated routing for strong/weak circuits, effectively resisting EMI interference from motors and relays in industrial sites.

5. Mature Process for Complex Industrial PCBA

Precise QFN mounting, wave soldering + post reinforcement for large through-hole power parts, heat sink assembly. Strictly control PCB warpage, cold solder and lifted components to satisfy vibration resistance and continuous working requirements of industrial equipment.

6. Full Custom One-stop Service

One-stop service including PCB prototyping, component sourcing, SMT, DIP and functional aging test. Fast delivery for small/medium batches and support customer project validation and mass production.

Application Fields

Automatic production line signal test equipment, laboratory multi-channel data acquisition instruments, industrial automation test jigs, semiconductor test fixtures, energy equipment signal acquisition boards, electromechanical controllers, environmental monitoring acquisition devices.

Manufacturing Capabilities of Juehui Weiye Circuit

Juehui Weiye Circuit provides one-stop PCB & PCBA services for industrial control and measurement instruments. We specialize in R&D and manufacturing of industrial mainboards, signal acquisition boards, high-power drive boards and test fixture boards.

✅ Expertise in multi-layer industrial PCB fabrication, high-precision QFN SMT assembly, wave soldering + post soldering reinforcement for large through-hole components and heat sink mounting.

✅ Pre-production DFM review, optimize power loop heat dissipation, high-speed signal impedance and creepage distance in advance to eliminate design risks.

✅ Full quality control: SPI, AOI, X-Ray, hipot test, power-on test and burn-in aging. Products comply with industrial EMC safety standards for stable long-term operation.

✅ Service Portfolio: One-stop solution for PCB prototyping, SMT assembly, DIP insertion, component sourcing and finished PCBA testing. Fast delivery for small & medium batches of industrial boards, supporting B-end customers on project verification and mass production.

Ordering Instructions

Please provide PCB Gerber files, BOM list, centroid coordinate files and functional test specifications. We offer quotation and manufacturing evaluation for full turnkey services including PCB production, SMT assembly and through-hole assembly. Board material, layer count, surface finish and component sourcing scheme can be adjusted upon request.
